19 inch Celeron J6412 Capacitive Panel PC SCP-D190SR

0 Reviews Write a review

Product codeSCP-D190SR

Availability In Stock

Estimated delivery dates: Apr 18, 2025 - Apr 22, 2025

$788.80 – $926.50
You save

● Support intel Celeron/Core i3, i5, i7 CPU, DDR3/4 memory, mSATA, M.2, 2.5 inch SATA hard drive
● Screen 19″ resolution 1280×1024, aluminum alloy front panel IP65 waterproof, optional capacitive touch screen or resistive touch screen
● Support power-on and boot, built-in double horns, high and low temperature resistance (-10 to 50°C) uninterrupted and stable operation, support grounding wire
● 6 DB9 RS232 COM ports, optional RS422/485 switching, support HDMI or VGA extended display, optional anti-vibration buffer waterproof adhesive strip
● 1 Gigabit Ethernet port (optional dual Ethernet port), 1 MINI-PCIE slot (optional WIFI Bluetooth or 4G module)
● Rugged chassis with or without fan for efficient heat dissipation, supporting embedded/VESA bracket and other mounting methods

Buy 1 - 9 pieces

~~$942.00~~

$800.70

Total:

$942.00

Buy 10 - 49 pieces

~~$942.00~~

$753.60

Total:

Buy 50 - 99 pieces

~~$942.00~~

$725.34

Total:

Buy 100+ pieces

~~$942.00~~

$697.08

Total:

Total：

Processor

Memory

Hard disk

Clear

Ask about product

TagsIndustrial control all-in-one machine, Industrial Panel PC

Overview

SCP-D190SR/SZ aluminum alloy industrial tablet PC is equipped with intel Celeron/Core processor, data storage supports mSATA, M.2, 2.5-inch SATA, rich COM (RS232/422/485), USB, LAN and other complete interfaces, expandable WIFI Bluetooth or 4G module, optional anti-vibration buffer waterproof adhesive strip to better prevent moisture from penetrating into the box, has been widely used in the industrial field and embedded equipment, It is also equipped with HDMI or VGA video output for extended display, supporting Windows and Linux systems.

It supports a wide temperature range (-10 to 50°C) and its streamlined design ensures efficient heat dissipation and strong shock resistance, making it a reliable industrial platform with safe grounding components to protect equipment more effectively. The screen adopts a 19-inch LED backlit industrial screen, the aluminum alloy front panel meets the IP65 waterproof standard, and the all-plane capacitive touch screen or resistive touch screen can be selected.

The embedded and VESA mounting methods can be quickly and flexibly installed in various environments, and can be applied to industrial automation, power communication, medical education, transportation, logistics and warehousing, smart city and other fields.

Specs

system	C P U	intel Celeron J1900/J4125/J6412、Core i3/i5/i7
	Display the core	intel HD Graphics
	Memory support	DDR3/4 SO-DIMM
	Hard disk support	mSATA/M.2/2.5 inch SATA
	Network chips	Gigabit Ethernet
	Audio chips	Integrated (built-in dual speakers)
	operating system	Support Windows/Linux
Interfaces	USB	6×USB
	Serial	6×DB9 RS232（Optional 1-3 switching RS485/422）
	Network interface	1×LAN 1000Mbps（2LAN port is optional）
	Extended display	1×VGA、1×HDMI
	Audio	1×Audio、1×Mic
	Power Supply	1×DC 12V、1×2pin
	Switch	1×Power
	Grounding	1×GND
	Wireless communication	1×MINI-PCIE（Optional expansion WIFI/Bluetooth/4G module）
Display	Screen type	19＂LED，5:4 Positive screen
	Resolution	1280×1024 @60Hz
	Display colors	16.7M
	Contrast ratio	1000:1
	Screen brightness	300~500cd/㎡
	Viewing angle	Horizontally 160°/vertically 150°
	Viewable area	377×303mm
Touch	Touch screen	Available capacitive touch screen or resistive touch screen
	Support contacts	10-point touch or 1-point touch
	Surface hardness	≧7H or ≧4H
	Light transmittance	＞87% or ＞79%
	Controls	USB
Structure	Front panel	Aluminum alloy: 5mm to thick, 2mm to thin
	Ingress protection	The front panel is IP65 waterproof and dustproof
	Chassis material	Galvanized steel SECC with ground terminal
	Heat dissipation	Fanned or fanless
	Power Specifications	DC 12V power adapter
	Installation	Embedded, VESA mount (100×100mm)
	Product dimensions	444×368×64mm
	Embedded cut-outs	424×348mm
	Package size	535×455×155mm
	Color	Silver (grayish)
	Weight	net weight 5.2kg，gross weight 6.6kg
Environment	Interference resistance	EMI/EMC Interference detection standards
	ESD static electricity	contact discharge ±8KV,air discharge ±15KV
	Anti-vibration	5~500Hz，2Grms random vibration
	Shock resistance	Working status: 10G@11ms，Non-working state: 20G@11ms
	Working environment	-10℃～50℃
	Storage environment	-20℃～60℃
	Relative humidity	10%～90%（No condensation）
